Effective and fast medication delivery

Low noise,powerful silent piston

Dual safety fuse on motor

With thermal protector

High quality motor

Oil free design


Features:
1. Oil free design.
2. High quality motor.
3. With thermal protector.
4. One button operation.
5. Sound Level ≤ 55dB (1 meter away from A500LW00).
6. Built-in nebulizer holder.
7. Effective and fast medication delivery.
8. Dual safety fuse on motor.
9. Ideal for all age.
10. Easy carry and handle.


 Specification:
Power  100V@60HZ,120V@60HZ,230V@50HZ,220V@60HZ
Power Consumption  180 VA Max
Sound Level  lower than 55 dB (1 meter away from A500LW03)
Compressor Pressure Range  29 to 52 Psi / 200 to 360 Kpa / 2 to 3.6 bar
Operating Pressure Range  13 to 19 Psi / 90 to 130 Kpa / 0.9 to 1.3 bar
Liter Flow Range  4.0 to 7.0 Lpm
Operating temperature Range  10 º C to 40 º C (50 º F to 104 º F )
Operating Humidity Range  10 to 90% RH
Storage temperature Range  -25º C to 70º C (-13º F to 158º F)
Storage Humidity Range  10 to 95% RH
Medication Capacity  6ml / 10ml (cc)
Partical Size  3 μm
MMAD  1.3 to 1.5μm / 3.4 to 4.0 μm
Average Nebulization Rate  ≥ 0.3 ml/min (2% saline solution)
Dimension(L×W×H)  176 mm×156 mm×88 mm
Net Weight  1.26 kg
Package Dimension(L×W×H)  240 mm×185 mm×130 mm
Gross Weight  1.76 kg
